Hikvision DS-2CE72DFT-FC
2 MP ColorVu Fixed Turret Camera
- 2 MP full time color turret camera
- 24/7 full color imaging
- Warm supplemental light with 20 m range
- Clear imaging even against strong back lighting due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- Water and dust resistant (IP67)
- 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Product Description
2 MP ColorVu Fixed Turret Camera
- 2 MP full time color turret camera
- 24/7 full color imaging
- Warm supplemental light with 20 m range
- Clear imaging even against strong back lighting due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- Water and dust resistant (IP67)
- 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Camera
| Image Sensor | 2 MP CMOS |
| Signal System | PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Frame Rate | TVI: 1080p@30fps, 1080p@25fps AHD: 1080p@30fps, 1080p@30fps CVI: 1080p@30fps, 1080p@25fps CVBS: PAL/NTSC |
| Min. illumination | Color: 0.0008 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Slow Shutter | Max. 16 times |
| Lens | 3.6 mm, 6 mm fixed lens |
| Field of View | 3.6 mm, horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0° 6 mm, horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7° |
| Lens Mount | M16 |
| Day & Night | Color |
| WDR (Wide Dynamic Range) | ≥120 dB |
| Angle Adjustment | Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360° |
Menu
| White Light | AUTO/OFF |
| Image Mode | STD/HIGH SAT |
| AGC | Yes |
| White Balance | Auto/Manual |
| AE (Auto Exposure) Mode | WDR/BLC/HLC/Global |
| Privacy Mask | 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Noise Reduction | 3D DNR |
| Language | English |
General
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption | Max. 3 W |
| Protection Level | IP67 |
| Material | Enclosure: Plastic Main Body: Metal |
| White Light | Up to 20 m |
| Communication | HIKVISION-C |
| Dimensions | Φ 109.82 mm × 85.56 mm (Φ 4.32" × 3.37") |
| Weight | Approx. 336 g (0.74 lb.) |
Download Hikvision DS-2CE72DFT-FC cc Camera Datasheet
Download Hikvision DS-2CE72DFT-FC cc camera installation guide
