Specification
| Camera | ||
| Image Sensor | 1/2.8″ CMOS | |
| Resolution | 1920 (H) × 1080 (V) | |
| Shutter Speed | Auto/Manual 1/3 s–1/100000 s | |
| Day & Night | Auto (ICR)/Color/B/W | |
| Min. Illumination | 0.01 Lux @F2.0 | |
| SNR (dB) | >56 dB | |
| Angle Adjustment | Pan: 0° to 355° Tilt: 0° to 78° Rotation: 0° to 360° |
|
| Others | Scanning System: Progressive ROM: 16 MB RAM: 64 MB |
|
| Lens | ||
| Lens Type | Fixed-focal | |
| Lens Mount | M12 | |
| Focal Length | 2.8 mm; 3.6 mm | |
| Aperture | 2.8 mm: F2.0 3.6 mm: F2.0 |
|
| Field of View | 2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120° 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100° |
|
| Iris Type | Fixed | |
| Close Focus Distance | 2.8 mm: 0.5 m (1.6 ft) 3.6 mm: 0.8 m (2.6 ft) |
|
| DORI Distance | 2.8 mm: 38.6 m(126.6 ft), 15.4 m(50.5 ft), 7.7 m( 25.3 ft), 3.9 m(12.8 ft) 3.6 mm: 49.7 m(163.1 ft), 19.9 m (65.3 ft), 9.9 m(32.5 ft), 5.0 m(16.4 ft) |
|
| Illuminator | ||
| IR LEDs | 12 (IR LED) | |
| IR Distance | 30 m (98.4 ft) | |
| Illuminator Control | Auto/Manual | |
| Video | ||
| Video Compression | H.265; H.264; H.264B; MJPEG (only supported by the sub stream) | |
| Resolution | 1080p (1920 × 1080); 1.3M(1280 × 960);720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | |
| Main Stream | 1920 × 1080 (1 fps–25/30 fps) | |
| Sub Stream | 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) |
|
| Smart Codec | Smart H.265+/Smart H.264+ | |
| Video Frame Rate | Main Stream:1920 × 1080 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) |
|
| Stream Capability | 2 streams | |
| Bit Rate Control | CBR/VBR | |
| Video Bit Rate | H.264: 32 kbps–6144 kbps H.265: 12 kbps–6400 kbps |
|
| Day/Night | Auto (ICR)/Color/B/W | |
| BLC | Yes | |
| HLC | Yes | |
| WDR | DWDR | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D NR | |
| Region of Interest (ROI) | Yes (4 areas) | |
| Mirror | Yes | |
| Privacy Masking | 4 areas | |
| Storage | ||
| Network Storage | FTP | |
| Network | ||
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast | |
| Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Genetec | |
| API | Yes | |
| User/Host | 6 (Total bandwidth: 36 M) | |
| Client | IOS; Android | |
| Web Browser | IE Chrome Firefox |
|
| App | Smart PSS; DSS; DMSS | |
| Interface | ||
| Network Interface | RJ-45 (10/100 Base-T) | |
| Alarm | ||
| General Alarm | Network disconnection; IP conflict; illegal access; motion detection; video tampering; safety exception | |
| Environment | ||
| Operating Temperature | -40°C to +60°C (-40°F to +140°F)/less than ≤ 95% | |
| Storage Temperature | -40°C to +60°C (-40°F to +140°F) | |
| Water Protection | IP67 | |
| Power | ||
| Power Supply | 12V DC/PoE (802.3af) | |
| PoE Standard | 802.3af | |
| Power Consumption | Basic power consumption:1.5W (12V DC); 3.3W (PoE) Max. power consumption (ICR + H.265+IR intensity): 2.3W (12V DC); 4.4W (PoE) |
|
| Physical Information | ||
| Casing Material | Inner core: Metal Cover: Plastic Decoration ring: Plastic Pedestal: Plastic |
|
| Dimension | 84.9 mm × Φ108 mm (3.3″ × Φ4.3″) | |
| Weight | Net Weight: 0.26 kg (0.5 lb) Gross Weight: 0.39 kg (0.8 lb) |
|
| Warranty Information | ||
| Warranty | 1 Year | |
