| Camera | ||
| Image Sensor | 2MP CMOS | |
| Max Resolution | 1920 × 1080 | |
| Min. Illumination | 0.0001 Lux @ F1.0 Color; 0 Lux with Illuminator On | |
| Signal System | CVI / TVI / AHD / CVBS | |
| Shutter Speed | PAL: 1/25s to 1/100,000s; NTSC: 1/30s to 1/100,000s | |
| Day/Night | Color | |
| Lens & Illuminator | ||
| Lens Type | Fixed-Focal Lens | |
| Field of View | 2.8mm: H 101°, V 53.4°, D 119.5°; 3.6mm: H 81.5°, V 44.3°, D 95.7° | |
| Aperture | F1.0 | |
| Lens Mount | M12 | |
| Light Type | Smart Light, 4 Warm Lights | |
| White/Warm Light Distance | Up to 50 m | |
| Video & Audio | ||
| Video Output | 1 × BNC, Switchable CVI / TVI / AHD / CVBS by DIP Switch | |
| Max Frame Rate | CVI / AHD / TVI: 1080p@25fps PAL, 1080p@30fps NTSC; CVBS: 960H PAL / NTSC | |
| Resolution Support | 1080p 1920 × 1080; 960H 960 × 576 / 960 × 480 | |
| WDR | 130dB | |
| Audio | Built-in Dual Microphone | |
| Pickup Distance | 12 m | |
| Audio Over Coax | Supported via CVI | |
| Image & Smart Functions | ||
| Image Enhancement | BLC, HLC, WDR, 3D Noise Reduction | |
| White Balance | Auto | |
| AGC | Auto Gain Control | |
| Image Control | Smart Light, Motion Detection, Mirror Control via XVR | |
| Motion Detection | Yes, Controlled Through XVR | |
| Smart Light / Smart IR | Smart Light Supported | |
| Mirror / Image Adjustment | Mirror Supported, Controlled Through XVR | |
| Interface | ||
| Audio Interface | Built-in Dual Mic | |
| Video Interface | 1 × BNC Video Output | |
| Physical Specification | ||
| Power Supply | 12V DC ±30% | |
| Power Consumption | Max. 5.6W, LED On | |
| Operating Temp | -40°C to +60°C; Humidity <95% RH, Non-Condensing | |
| Material | Dome: Metal + Plastic; Enclosure: Plastic | |
| Weatherproof | IP67 | |
| Installation | Wall Mount, Ceiling Mount, Vertical Pole Mount | |
| Dimensions | Φ109.9 × 102.2 mm | |
| Weight | Net: 0.33 kg; Gross: 0.45 kg | |
| Certifications | CE-LVD: EN 62368-1; CE-EMC: EN 55032, EN 55035 | |
| Warranty | ||
| Warranty | 1 Year | |
