Specification
| Audio and Video | ||
| IP Camera Input | Support up to 16-ch | |
| Two-Way Talk | 1-ch, RCA (2.0 Vp-p, 1 KΩ) | |
| Display | ||
| Resolution | Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. | |
| Decoding Capacity | 16-ch @ 1080p (30 fps) | |
| Recording | ||
| Compression | G.711ulaw/G.711alaw/G.722/G.726/MP2L2 | |
| Resolution | 16-ch Up to 12 MP resolution *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. | |
| Video Detection And Alarm | ||
| Alarm Input | In/Out: 16/8 | |
| Playback And Backup | ||
| Sync Playback | 16-ch | |
| Playback Function | Normal/Smart, Event, Tag, Eternal File | |
| Network | ||
| Interface | 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface | |
| Ethernet Port | Yes | |
| Storage | ||
| Internal HDD | Up to 10TB capacity for each disk | |
| eSATA | 4 SATA | |
| Auxiliary Interface | ||
| USB | 2 x USB 2.0 (Front), 1 x USB 3.0 (Rear) | |
| Power | ||
| Power Supply | 12 VDC, 2.1 A | |
| Power Consumption | 30W (without HDD) | |
| Construction | ||
| Dimensions | 445 x 400 x 75mm | |
| Net Weight | 5.6 kg | |
| Warranty | ||
| Manufacturing Warranty | 1 year warranty | |
