SPECIFICATIONS
Storage
Internal or ExternalInternal HDD
Display
Resolution1920×1080, 1280×1024, 1280×720, 1024×768
Camera
CameraHDCVI Camera Input: 32 Channel
IP Camera Input: 16 Channel (Each up to 5MP)
Networking & Connectivity
Ethernet1 × RJ-45 Port (1000M)
Audio & Microphone
Bit Rate1Kbps ~ 4096Kbps Per Channel
Battery And Power
Power SupplyDC 12V / 4A
Power Consumption< 20W (Without HDD)
Ports
PortHDMI, VGA, TV Output
USB2 × USB (1× USB 3.0, 1× USB 2.0)
Video Features
Video FeaturesMotion Detection
Video Loss Detection
Video Tampering
Digital Zoom
Multi-screen Display (1/4/8/9/16/25)
Special Features
ModesManual, Schedule, Motion Detection, Alarm, Stop
Others
COMPRESSION STANDARDH.264
Other FeaturesP2P Support
Mobile Monitoring (Android, iPhone, iPad)
ONVIF 2.4.2 Support
Third-party Camera Support
Physical Specification
EnvironmentOperating: -10°C ~ +55°C
Storage: -20°C ~ +70°C
Net Weight2kg (Without HDD)
Dimension375mm × 287mm × 53mm (1U)
Technical Info
Video And AudioH.264 Video Compression, RCA Audio In/Out (1/1)
Main FunctionsRecording, Playback, Backup, Remote Monitoring, PTZ Control
Record RateMain Stream: Up to 25/30fps
Sub Stream: CIF/QCIF (1~7fps)
Sync Playback1 / 4 / 9 / 16 Channel
Warranty Information
Warranty1 Year
