| Camera | ||
| Image Sensor | 2MP CMOS | |
| Max Resolution | 1920 × 1080 | |
| Min. Illumination | 0.0002 Lux @ F1.6 Color; 0 Lux with Illuminator On | |
| Signal System | CVI / TVI / AHD / CVBS | |
| Shutter Speed | PAL: 1/25s to 1/100,000s; NTSC: 1/30s to 1/100,000s | |
| Day/Night | Color | |
| Lens & Illuminator | ||
| Lens Type | Fixed-Focal Lens | |
| Field of View | 2.8mm: H 103.7°, V 56.8°, D 121.4°; 3.6mm: H 82.7°, V 45°, D 96.4° | |
| Aperture | F1.6 | |
| Lens Mount | M12 | |
| Light Type | Smart Light, Warm Light | |
| White/Warm Light Distance | Up to 30 m | |
| Video & Audio | ||
| Video Output | 1 × BNC, Switchable CVI / TVI / AHD / CVBS | |
| Max Frame Rate | CVI / AHD / TVI: 1080p@25fps PAL, 1080p@30fps NTSC; CVBS: 960H@50fps PAL, 960H@60fps NTSC | |
| Resolution Support | 1080p 1920 × 1080; 960H 960 × 576 / 960 × 480 | |
| WDR | DWDR | |
| Audio | Built-in Microphone | |
| Pickup Distance | 8 m | |
| Audio Over Coax | Supported via CVI / TVI | |
| Image & Smart Functions | ||
| Image Enhancement | BLC, HLC, WDR, HLC-Pro, DWDR, 3D Noise Reduction | |
| White Balance | Auto | |
| AGC | Auto Gain Control | |
| Image Control | Smart Light, Motion Detection, Mirror Control via XVR | |
| Motion Detection | Yes, Controlled Through XVR | |
| Smart Light / Smart IR | Smart Light Supported | |
| Mirror / Image Adjustment | Mirror Supported, Controlled Through XVR | |
| Interface | ||
| Audio Interface | Built-in Mic | |
| Video Interface | 1 × BNC Video Output | |
| Physical Specification | ||
| Power Supply | 12V DC ±30% | |
| Power Consumption | Max. 3.2W | |
| Operating Temp | -40°C to +60°C | |
| Material | Plastic | |
| Weatherproof | IP67 | |
| Installation | Wall Mount, Ceiling Mount, Vertical Pole Mount | |
| Dimensions | Φ94.0 × 83.7 mm | |
| Weight | Net: 0.21 kg; Gross: 0.30 kg | |
| Certifications | CE-LVD: EN 62368-1; CE-EMC: EN 55032, EN 55035 | |
| Warranty | ||
| Warranty | 1 Year | |
