Specification
| Camera Feature | ||
| Image Sensor | 1/2.8″ Progressive Scan CMOS | |
| Effective Pixels | 2MP | |
| IR Distance | Up to 30 m | |
| Others | Max. Resolution: 1920 × 1080 Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light Shutter Time: 1 s to 1/100,000 s Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
|
| Lens | ||
| Type | 4mm | |
| Focal Length | Fixed focal lens | |
| Aperture | F1.0 | |
| Angle of View | horizontal FOV 88°, vertical FOV 47°, diagonal FOV 103° | |
| Others | Motion detection (support alarm triggering by specified target types (person and vehicle)), video tampering alarm, exception |
|
| Physical Specification | ||
| Dimension | 69.8 mm × 67.9 mm × 172.9 mm (2.7″ × 2.7″ × 6.8″) | |
| Weight | Approx. 550 g (1.2 lb.) | |
| Power | 12 VDC ± 25%, 0.55 A, max. 6.6 W,Ø 5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8 W |
|
| Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port built-in microphone |
|
| Others | Water and dust resistant (IP67) | |
| Warranty | ||
| Warranty | 2 Year | |
