Specification
| Camera Feature | ||
| Image Sensor | 1/3″ Progressive Scan CMOS | |
| Effective Pixels | 4 Megapixel | |
| IR Distance | Up to 30m | |
| Lens | ||
| Type | Fixed | |
| Focal Length | 2.8 and 4 mm optional | |
| Aperture | F1.6 | |
| Angle of View | 2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° 4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93° |
|
| Others | Lens Mount: M12 | |
| Physical Specification | ||
| Dimension | Ø 121.4 mm × 97.7 mm (Ø 4.8″ × 3.8″) | |
| Weight | Approx. 550 g (1.2 lb.) | |
| Power | 12 VDC ± 25%, 0.5 A, max. 6 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
|
| Interface | Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
| Warranty | ||
| Warranty | 1 Year | |
